Traxxas

TRX-4 Ford F-150 High Trail Edition

$549.95 USD

Sale Sold out

Shipping calculated at checkout.

Color Blue Brown Black

Product variants

SKU:92046-4

Quantity

TRX-4 Ford F-150 High Trail Edition

Officially Licensed 1979 Ford^® F-150^® Ranger XLT Body
- Scale details: grille, chrome bumpers, side mirrors, door handles, and wipers
- LED-ready headlights, tail lights, and roll bar
- Authentic decal sheet
- Full Nylon composite wheel wells and floor pans
Clipless Body mounting
- Clipless design for smooth body appearance
- Rugged internal body cage for added rigidity
Trail-tuned XL-5™ HV Waterproof Electronic Speed Control
- Fully waterproof design
- Five drive profiles
  - Sport Mode — forward / brake / reverse
  - Race Mode — forward / brake / no reverse
  - Training Mode™ - 50% forward / 100% brake / 50% reverse (patented)
  - Trail Mode — forward / brake / reverse / with trail-tuned drag brake in neutral
  - Crawl Mode — forward / instant reverse - no neutral with 100% hill holding brake
- Traxxas EZ-Set^® one-button setup
- Large, efficient heat sink
- Wide voltage latitude 6–7 cell NiMH (7.2–8.4 V) and 2–3s LiPo (7.4–11.1 V)
- Two stage low voltage protection (LVD)
Titan^® 550 Motor
- Powerful Titan 21T reverse rotation motor with internal cooling fan
- Precision, preset gear mesh adjustments
- Motor retention separate from gear mesh
Portal Axles
- Increase ground clearance
- Eliminate torque twist
- Steel gears
- Improve axle geometry and reduce strain on driveshafts

Drivetrain
- Full-time shaft driven 4-wheel drive
- Tough 6 mm stub axles
- Steel front CV driveshafts
- Hardened steel rear axle shafts
- Remote locking steel gear differentials with cable-actuation
- Steel gear transfer case
Factory-Installed Long Arm Lift Kit
- Increases ground clearance over 1″
- Maintains precise steering geometry
- Accommodates oversize 2.2″ wheels and tires
TQi™ 2.4 GHz Radio System
- 4-channel transmitter
- 5-channel micro receiver (6533) with fail-safe security and integrated telemetry ports
- Compatible with optional TQi Traxxas Link Wireless Module (6511) to access full Traxxas Link app functionality (sold separately)
- Automatically stores and loads settings for up to 30 Traxxas Link enabled models
- Exclusive Cruise Control feature for extended trail driving
- Adjustable steering and throttle sensitivity (exponential)
- Adjustable steering and throttle endpoints
- Patented waterproof receiver box with easy-access plug
Extended Wheelbase
- Long 336 mm wheelbase for improved stability
- Full-length 1.5 mm thick steel frame rails
- Bumpers adjust fore and aft
- Rugged rock rails adjust for width
- Wire routing clips integrated into frame rails
Innovative Battery Compartment
- Hinged battery strap allows quick and easy battery access
- No pins to lose
- Accommodates different height batteries
- Accepts full-size long battery packs
- Integrated compartment accepts smaller 1/16 scale batteries (with optional strap)
- Secondary front battery tray accepts smaller 1/16 scale batteries (with optional strap)

Transmission
- Two speed high/low range with remote shifting
- Dual horizontal shafts
- Twin friction plate slipper clutch
- Easily removed for servicing
Steering
- Chassis mounted 2075X metal gear digital servo
- Superior 45° steering angle
- Direct steering (no servo saver)
- Steering geometry corrected for bump steer
Suspension
- Front — 3 link with panhard
- Rear — Triangulated 4 link
- Heavy-duty rod ends with steel hollow balls
- 5 mm diameter steel link rods with 4 mm threaded ends
Extended Aluminum GTS Shocks
- Oil-filled coilover GTS shocks exclusive to TRX-4 chassis
- Extra-long aluminum bodies for greater articulation
- Silver-anodized aluminum bodies
- Threaded bodies with collars easily adjust ride height
- Silky smooth damping for the toughest trails
- O-ring cap seal and dual X-ring shaft seals
Oversize Wheels and Tires
- 2.2″ slotted mag wheels wheels with hub inserts
- Pre-mounted 2.2″ Canyon Trail tires with trail-tuned foam inserts
- Trail tuned S1 rubber compound
- 12 mm steel hex
Sealed Ball Bearings
Hex hardware with Rust-Resistant Black Oxide Coating
Requires Battery and Charger (Sold Separately)

Model Specs

Model Name:	TRX-4 Ford F-150 High Trail Edition
Model Type:	Trail / Crawler
Model Skill Level:	1
Chassis:	Extended steel ladder frame
Scale:	1/10
Weight:	7.34 lb (3.33 kg)
Length:	22.30 inches (566 mm)
Width:	10.60 inches (270 mm)
Front Track:	10.60 inches (270 mm)
Rear Track:	10.60 inches (270 mm)

Height:	10.82 inches (275 mm)
Wheelbase:	13.23 inches (336 mm)
Center Ground Clearance:	4 inches (99 mm)
Drivetrain:	Shaft-driven 4WD
Transmission:	2-speed high/low, remote shifting
Differential Type:	4 gear, remote locking
Gear Pitch:	32 pitch
Servo(s):	2075X metal gear, digital high-torque waterproof
Radio System:	TQi™ 2.4 GHz 4-channel transmitter with 6533 receiver
Battery Compartment Specs:	159 mm X 47 mm X 23 mm, 26 mm

Motor Specs

Motor Name:	Titan® 550 21T reverse rotation
Motor Type:	High-torque brushed motor
Motor Weight:	390g (13.76 oz)
Motor Length:	3.071″ (78 mm) overall length, 2.25″ (57 mm) can length
Motor Diameter:	1.532″ (39 mm diameter)
Motor Shaft Size:	3 mm
Motor Connector Type:	Bullet

ESC Specs

ESC Name:	XL-5™ HV
ESC Type:	Brushed
ESC Case Size:	1.23 inches (31 mm) / 2.18 inches (55 mm) / 1.04 inches (26 mm)
ESC Weight:	2.6 ounces (74 g)
Motor Connectors:	Bullet
Battery Connectors:	Traxxas High-Current Connector
ESC Power Wire:	14 gauge

Traxxas TRX-4 High Trail RC Crawler with '79 Ford F-150 Body

The Traxxas TRX-4 1/10 High Trail Edition RC Crawler with '79 Ford F-150 Ranger XLT Truck Body has been designed to offer scale performance and adventure. Thanks to its factory-installed Long Arm Lift Kit and oversized tires, the highly detailed 79 Ford F-150 Ranger XLT body stands over an inch taller than the standard TRX-4 chassis. The F-150's extended wheelbase further enhances the TRX-4’s legendary off-road capability for better performance on the trail. To further the appearance, this truck uses the Traxxas Clipless Body Mounting for added scale realism. The TRX-4 High Trail Edition is the perfect vehicle for the driver who wants it all: extreme all-terrain capability, stunning scale looks, and extreme durability.

This High Trail Edition TRX-4 uses portal axles, 110mm threaded shocks and a lift kit for extreme ground clearance. Oversized Canyon Trail tires are mounted to chrome 2.2" wheels to improve both performance and ground clearance. When the going gets tough, use your transmitter to shift into low range for incredible 4-wheel drive pulling torque. Shift into high range for blasting down the trail. Traxxas gives you the versatility to lock and unlock the front and rear differentials to suit your driving needs directly from your transmitter. Leave the differentials unlocked for relaxed driving on the trail with smooth, tight turning and better handling at high speeds. When the trail gets technical, lock the front and rear differentials, or just the front, for superior grip over extreme terrain.

Features:

Molded Scale Detail: The 1979 Ford F-150 Ranger XLT Pickup Body comes with authentic-looking chrome wheels, side mirrors and windshield wipers.
Clip-less Body Mounting System: Traditional posts and body clips are gone, and instead an integrated quick-release system secures the body invisibly. The hidden mechanism holds tight on the trail yet releases in just seconds to access the chassis.
Trail-tuned XL-5 HV Waterproof Electronic Speed Control: HV electronic speed control brings 3s LiPo capability for strong efficient running. The powerful 21T Titan motor provides torque for hauling heavy loads and climbing steep grades.
Factory-Installed Long Arm Lift Kit: The lift kit not only gives you an extra inch of ground clearance but also maintains the TRX-4's suspension geometry.
Extended Wheelbase: The K10’s steel frame rails extend the wheelbase out to 336mm to capture the pickup’s real-world proportions perfectly.
The Power of Portals: The K10’s portal axles work in tandem with the Lift Kit to lift the truck for huge center ground clearance. The portal axles’ internal gear reduction virtually eliminates torque twist, keeping the K10 straight and on course.
Extended Aluminum GTS Shocks: These shocks are 20mm longer than the standard GTS shocks. The threaded shock bodies are silver-anodized to deliver silky-smooth dampening.
Oversize Wheels and Tires: The aggressive Canyon Trail tires feature large lugs for increased grip with foam inserts for realistic trail performance. Slotted chrome Mag wheels come with replica locking hubs to conceal the wheel nuts.
Sealed Ball Bearings: Reliable sealed ball bearings are used throughout the chassis for long-lasting performance.
